Product Details
＋
Special DI box with loadbox for guitars. The integrated load resistor permits tube amplifiers up to approximately 120 W to be connected to the PGA04, bypassing a loudspeaker. A jack socket (unbalanced) and balanced XLR connector are available for direct pickup of the signal. The extensive filter section provides for a realistic simulation of classic guitar loudspeaker sounds.
| Product type | Speaker Simulators |
| Channels | 1 |
| Input type | unbalanced |
| Inputs | 1 |
| Input connectors | 6.3 mm jack |
| Output type | balanced , unbalanced |
| Outputs | 2 |
| Output connectors | 6.3 mm jack , XLR |
| Output impedance | 10 k (6.3 mm Jack) Ohm(s) , 600 (XLR) Ohm(s) |
| Controls | colour , filter volume , fullrange volume , high , high cut , low |
| Indicators | max. load |
| Dummy load | Yes |
| Dummy load impedance | 16 Ohm(s) |
| Max. load | 100 W |
| Voicing filter | Yes |
| Power attenuator | no |
| transformer balanced inputs | no |
| Transformer isolated outputs | Yes |
| Cabinet material | sheet steel |
| Cabinet surface | Powder coated |
| Width | 480 mm |
| Width | 19 " |
| Depth | 180 mm |
| Height | 44.5 mm |
| Height | 1 U |
| Weight | 2,56 kg |
